Two Digit Timer/Counter Using Arduino

by RifahT in Circuits > Electronics

627 Views, 1 Favorites, 0 Comments

Two Digit Timer/Counter Using Arduino


Arduino Two Digit Counter made on TinkerCAD in only a few simple and easy to follow steps! Simple materials and easy wiring for an amazing project.

Supplies

- Arduino UNO

- 1K Resistors (4)

- 7 Segment Displays (2)

- CD4511 (2)

- Jumper Wires

- Push Button

Building the Circuit


Wire the components on the breadboard and follow the simple wiring as shown above.

Code


I have going used text code for m project but you can also go ahead and do block or blocks and text. The code may look really long but is very simple since its just mostly repeated functions.

You can access to the code using the link below or just ask me for the new link if it expires.

https://www.tinkercad.com/things/7xgL1IVTFHN-neat-stantia/editel?sharecode=MkHxqlqHQGEq51bnQhS5FeM-a2E-2OpDHajINLYc23Y

Link

https://www.tinkercad.com/things/7xgL1IVTFHN-neat-stantia/editel?sharecode=MkHxqlqHQGEq51bnQhS5FeM-a2E-2OpDHajINLYc23Y
