ACS712 Current Sensor (30A) Tutorial, 100% Working, Easy Way, Interface With Arduino, Code Given

Description:

• Current sensor chip: ACS712ELC-30A
• Pin 5V power supply, onboard power indicator
• The module can measure positive and negative 30 amp current, corresponding to the analog output 100mV/ A

• When no detection current is passed, the output voltage is VCC/2
• The current to be detected is connected in series to the terminal
• PCB board size: 31 (mm) x 13 (mm)

ACS712 CURRENT SENSOR MODULE (30A)

3-6V 130 SMALL DC MOTOR RPM17000

ARDUINO UNO

JUMPER WIRE

Arduino Library For ACS712 Current Sensor
