Tutorial: How to Build a VL53L0X Laser Ranging Sensor Module by Using Arduino UNO

Descriptions:

This tutorial will show to all you guys in details on how to build distance detector by using VL53L0X Laser Ranging Sensor Module And Arduino UNO and it will run like you want. Follow the instructions and you will understand this tutorial.

The VL53L0X time-of-flight ranging sensor is a new generation of laser ranging module. VL53LOX is a fully integrated sensor with embedded infrared, human eye safety laser. Advanced filter and ultra-high speed photon detection array for longer distance measurement and speed. Higher precision. The sensing capability of the VL53L0X can support a variety of functions, including gesture sensing or proximity detection for various innovative user interfaces. Obstacle detection and collision avoidance systems for sweeping robots, service robots, home appliance sensing panels, and laptop users. Detection or power switch monitors, as well as drones and Internet of Things (IoT) products, etc

Specifications:

• Material: circuit board
• Color: purple
• Working voltage: 3 ~ 5V
• Communication method: IIC
• Measuring absolute distance: 2mXshutdown (reset) / GPIO (interrupt)
• Product size: 2.5*1.2*0.5cm

All the circuit or module or component that we have use in this tutorial, you can get all that on link that given below :

VL53LOX LASER RANGING SENSOR MODULE (TOF)

Arduino UNO

Jumper Wires

VL53L0X Library
