Triggering Multiple Solenoids With Multiple Buttons
by Select All Vertical Rivers in Circuits > Arduino
480 Views, 2 Favorites, 0 Comments
Triggering Multiple Solenoids With Multiple Buttons

Here is how you can trigger multiple small solenoids with multiple buttons using an Arduino. This example triggers five solenoids with five buttons.
Supplies
- solenoids
- buttons
- Arduino Uno
- jumper wires
- breadboard
- 12v power supply
- TIP120 (x5)
- 4007 power Diodes (x5)
- 10k ohm resistors (x5)
- 2.2k resistors (x 5)
Circuits


the pdf contains the combined wiring diagram.
