Electromagnetic Inductor

DIY Electromagnetic Inductor
Screenshot 2015-04-14 18.32.37.png

To understand the theory of electromagnetic motors. watch opening 3 minutes of this video
Components Used:

C or D Battery (1pcs)

1m of solid core copper wire

Iron all thread M6 or larger.

Tools used:

Sandpaper sheet

Lighter

Pliers

Wrap the Copper Wire Around the All-thread and Close Off the Ends With Insulation Tape

Screenshot 2015-04-14 18.34.20.png
Screenshot 2015-04-14 18.34.52.png

Connect the Battery to the Ends of the Wire

Screenshot 2015-04-14 21.35.35.png
Screenshot 2015-04-14 21.35.00.png

Test Out Your Inductor on a Compass and Some Nails

Screenshot 2015-04-14 18.35.54.png
Screenshot 2015-04-14 18.36.11.png

Your inductor should be a temporary magnet as long as the wire is connected to the battery.
