Speaking Clock With AVR
by arick in Circuits > Microcontrollers
2950 Views, 19 Favorites, 0 Comments
Speaking Clock With AVR
![AVR Speaking clock (2).jpg](/proxy/?url=https://content.instructables.com/FSO/8QEB/HTUFCEDR/FSO8QEBHTUFCEDR.jpg&filename=AVR Speaking clock (2).jpg)
Guys,
I have created a clock with ability on speaking so it tells me every 1.00,1.30,and so on...
I don't have to see the clock anymore just hear and I know what time is it
Let's get started...
I have created a clock with ability on speaking so it tells me every 1.00,1.30,and so on...
I don't have to see the clock anymore just hear and I know what time is it
Let's get started...
Spare Parts Needed..
![AVR Speaking clock (4).jpg](/proxy/?url=https://content.instructables.com/FKS/B6V1/HTURZQB5/FKSB6V1HTURZQB5.jpg&filename=AVR Speaking clock (4).jpg)
![AVR Speaking clock (3).jpg](/proxy/?url=https://content.instructables.com/FM7/ETHA/HTUV8KLY/FM7ETHAHTUV8KLY.jpg&filename=AVR Speaking clock (3).jpg)
![AVR Speaking clock (5).jpg](/proxy/?url=https://content.instructables.com/FD8/QXUR/HTURZQBF/FD8QXURHTURZQBF.jpg&filename=AVR Speaking clock (5).jpg)
![AVR Speaking clock (1).jpg](/proxy/?url=https://content.instructables.com/FML/3ZQY/HTUFCEE4/FML3ZQYHTUFCEE4.jpg&filename=AVR Speaking clock (1).jpg)
![AVR Speaking clock (2).jpg](/proxy/?url=https://content.instructables.com/F5S/6MRK/HTUFCEE5/F5S6MRKHTUFCEE5.jpg&filename=AVR Speaking clock (2).jpg)
1.AVR microcontroller
2. DSP chip from VLSI
3. USBASB
4. Speaker
5. Amplifier, I use LM386, but you can use whatever you like
6. LCD module
7 RTC
8. SDcard
2. DSP chip from VLSI
3. USBASB
4. Speaker
5. Amplifier, I use LM386, but you can use whatever you like
6. LCD module
7 RTC
8. SDcard
The Code...
![code.jpg](/proxy/?url=https://content.instructables.com/FFX/WBRC/HTURZQD9/FFXWBRCHTURZQD9.jpg&filename=code.jpg)
I made some init code for LCD,SD card and VLSI chip
and it was done on atmel studio..
and it was done on atmel studio..
Let's Watch the Clock Speaking...
![AVR Speaking clock (2).jpg](/proxy/?url=https://content.instructables.com/FLB/O9K5/HTURZQJ9/FLBO9K5HTURZQJ9.jpg&filename=AVR Speaking clock (2).jpg)
Thanks for reading folks....
