Simple Beam Compass Instructable

Screen Shot 2018-07-01 at 3.36.30 AM.png

This is the simplest/ easiest way that I could think of, of making a large compass. Enjoy!

How to Draw Big Circles by Making a Simple Beam Compass

Watch the video, or scroll below for all the steps.

Gather Materials

Screen Shot 2018-07-01 at 3.36.47 AM.png

Gather 2 pieces of identical length wood for the 'beam', and 2 identical pieces for the inner channel. Also two misc sized pieces for the pencil hole. The sizes you choose dont matter, just as long as they are the same.

Glue the Small Pieces on Either Inner End of the Long Stick.

Screen Shot 2018-07-01 at 3.37.11 AM.png

Create a Sandwich the Next Long Piece - Using Glue to Adhere Them Together

Screen Shot 2018-07-01 at 3.37.50 AM.png

Drill a Hole Into the Pencil Holder

Screen Shot 2018-07-01 at 3.38.11 AM.png

Attach the Pencil Holder to the Rest of the Body of the Compass

Screen Shot 2018-07-01 at 3.38.50 AM.png

Find a Bolt With a Pointy End and a Bolt + Washer

Screen Shot 2018-07-01 at 3.39.33 AM.png

The Final Step

Screen Shot 2018-07-01 at 3.39.47 AM.png

Stick bolt and nut through channel, and pencil in hole- the ruler is now ready for use!
