Rotate Sand CLOCK Every Minute Using Servo Motor - Arduino

In this tutorial we will learn how to rotate a small (1 minute) sand clock every 60s using servo motor and Visuino,

Watch a demonstration video.

• Arduino UNO (or any other Arduino)
• Sand clock
• Servo motor
• some small wire or glue to attach the clock to the motor
• jumper wires
• Visuino program: Download Visuino

• Connect Servo motor "Orange" pin to Arduino Digital pin[2]
• Connect Servo motor "Red" pin to Arduino positive pin[5V]
• Connect Servo motor "Brown" pin to Arduino negative pin[GND]

To start programming the Arduino, you will need to have the Arduino IDE installed from here: https://www.arduino.cc/.

Please be aware that there are some critical bugs in Arduino IDE 1.6.6. Make sure that you install 1.6.7 or higher, otherwise this Instructable will not work! If you have not done follow the steps in this Instructable to setup the Arduino IDE to program Arduino UNO! The Visuino: https://www.visuino.eu also needs to be installed. Start Visuino as shown in the first picture Click on the "Tools" button on the Arduino component (Picture 1) in Visuino When the dialog appears, select "Arduino UNO" as shown on Picture 2

• Add "Clock Generator" component
• Add "Toggle(T) Flip-Flop" component
• Add "Analog Value" component
• Add "Servo" component

• Select "ClockGenerator1" and in the properties window set "Frequency" to: 0.0166667 <<this is 60s, you can change the number if you want
• Select "AnalogValue1" and in the properties window set "Value" to 1
• Double click on "AnalogValue1" and in the elements window drag 2X 'Set Value' to the left side
  Select 'Set Value2' and in the properties window set "Value" to 1

• Connect "ClockGenerator1" pin [Out] to "TFlipFlop1" pin[clock]
• Connect "TFlipFlop1" pin [Out] to "AnalogValue1">"Set Value0" pin[In]
• Connect "TFlipFlop1" pin [Inverted] to "AnalogValue1">"Set Value1" pin[In]
• Connect "AnalogValue1" pin[Out" to "Servo1" pin[In]
• Connect "Servo1" pin[Out] to Arduino board digital pin[2]

In Visuino, at the bottom click on the "Build" Tab, make sure the correct port is selected, then click on the "Compile/Build and Upload" button.

If you power the Arduino UNO module, the servo motor will rotate a sand clock every minute.

Congratulations! You have completed your project with Visuino. Also attached is the Visuino project, that I created for this Instructable, you can download it here and open it in Visuino: https://www.visuino.eu
