Obstacle Avoiding Robot Simulation
Hello Everyone!!
Welcome to my Instructables
In this Post Im gonna Teach you guys how to create a obstacle avoiding robot simulation using the software called TinkerCAD
It's very easy to create this obstacle avoiding robot
Components
I have used:
1. Ultra Sonic Sensor(1no.)
2. Breadboard(1no.)
3. Motor(2no.)
4. L293d(1no.)
5. Arduino(1no.)
Circuit
Join the wires as shown in the picture to create the circuit
Coding
After you have joined your wires and completed you circuit
code the simulation as shown in the picture so that your virtual obstacle avoiding robot can change it's direction when a obstacle is less than 15cm forward
