Obstacle Avoiding Robot Circuit
by Gautam Aravindan in Circuits > Arduino
162 Views, 0 Favorites, 0 Comments
Obstacle Avoiding Robot Circuit
This is an obstacle avoiding robot. In this i am showing my simulation of a robot which turns to the left when it senses and object in front of it within 15 cm. This is the virtual simulation which can be followed in real life and can be built .
Components Required
Components required are :
1)Arduino uno -1
2) Bread board -1
3) L293D -1
4) motors -2
5) Ultrasonic sensor (HC SR04) -2
Connections
Make the following connections using the tinker cad software . Shown in the image
The Code Blocks
Assemble the following code blocks using the tinker cad software . Shown in the picture
