Nixie Watch Prototope_a V5. Full Datasheet

14263968_1749878548615072_3173974680093314436_n (1).jpg

Hello.

This is full source code + datasheet + all what you need to build your own nixie watch.

This is new revision of model prototype_a. Now it is archiewed version.

This watch was build for my friend. Casing - brass, bracelett -leather.

If someone need inspiration or small worklog - write in coments, or check my instagram/FaceBook page.

Previous prototype_a alpha on instructables that use Transformer as power source https://www.instructables.com/id/Nixie-Watch-Proto... on this project source was lost due hdd milfunction

Build your own Steampunk Nixie watch

Note that wach work on hight voltage!!!

Note that youll need some junk from ebay!!!

Characteristics

Rechargeable battery via micro-USB.

Description: This is Fully Assembled and Tested Nixie Watch with 4 Pieces IN-16 NOS Tubes + 1 Tube blink. Power By: DC 5V via rechargeable battery or via USB cord. Time before recharging: 12-16 hours in active mode or more than month in passive mode User Selectable: 24HH-MM-SS/ DD-MM-YY / Energy level/ Change on - off Dimension: Width 76mm x Height 50mm x Depth 26mm

(+- this depend of your casing. 3d printed or not\design etc)

Handmade!

Little video https://instagram.com/p/08F--GMSeH/?taken-by=prot...

On next Step datasheet
