How to Make LED Board | Channel Logo Using Multi Color LEDs

by Indian DIYers in Circuits > LEDs

1845 Views, 7 Favorites, 0 Comments

How to Make LED Board | Channel Logo Using Multi Color LEDs

How to make a blinking LED board|Make a LED board with your name or Logo.

If you see my previous project(serial LED light using multicolor LDs) then you might know i bought 1000pcs LED for my project but I did not use all LEDs in my project and there are hundreds of LEDs are Left So' I thought I can use this to make my channel logo(see image) and I started to make it....So in this post i am going to share my experience and HOW CAN YOUR MAKE YOUR OWN LED Board... Make a name plate for your love ones.....Lets start..........

Step 1:-Materials and Tools Required


I am using 5mm LEDs (multicolor) for the board and About 9*14cm of Purfboard and Some jumpers soldering iron, soldering paste, soldering wire, Wire stripper,5 to9 Volt Adapter & a DC jack.All the materials and tools are listed below and you can find this in your local hobby shop as well as electronics shop...Here is the full material list and use images as reference.....

1)5mm LEDs (no.of leds are depend on your board size)

2)5 or 9 volt Adapter

3)DC jack

4)jumpers and wires

5)soldering iron

6)soldering paste

7)soldering wire

I bught this materials from local electronics shop in India.......Lets make it....

Step 2:- How to Make My Own...

How to make a blinking LED board|Make a LED board with your name or Logo.

After getting all listed materials make a rough design on purfboard(you can us Cardboard as well) using marker pen and place The LEDs parallely on the board use jumpers if required(like in image) and first make full design using LEDs and after placing all LEDs as your design Solder the terminals of LEDs on purfboard(+ve to +Ve and -Ve to-Ve). After soldering all things in it's place connect DC jack to the board.....and ..here your logo or Name plate is ready...

Connect the Dc adapter of 5 or 9 volt and switch on the adapter ...Here your board is glowing..if it's not glowing check your connection properly and try again....Here is how my board..AKA..my channel logo looks like...Check video...

if you found this post helpful then press like....&....If you have any question about it comment below...

Thanks for visiting my post.....
