Mini Computer Smart Watch
Supplies
Code.
# Note you can change the I2C address by passing an i2c_address parameter like:
# disp = Adafruit_SSD1306.SSD1306_128_64(rst=RST, i2c_address=0x3C)
# Alternatively you can specify an explicit I2C bus number, for example
# with the 128x32 display you would use:
# disp = Adafruit_SSD1306.SSD1306_128_32(rst=RST, i2c_bus=2)
# 128x32 display with hardware SPI:
# disp = Adafruit_SSD1306.SSD1306_128_32(rst=RST, dc=DC, spi=SPI.SpiDev(SPI_PORT, SPI_DEVICE, max_speed_hz=8000000))
# 128x64 display with hardware SPI:
# disp = Adafruit_SSD1306.SSD1306_128_64(rst=RST, dc=DC, spi=SPI.SpiDev(SPI_PORT, SPI_DEVICE, max_speed_hz=8000000))
# Alternatively you can specify a software SPI implementation by providing
# digital GPIO pin numbers for all the required display pins. For example
# on a Raspberry Pi with the 128x32 display you might use:
# disp = Adafruit_SSD1306.SSD1306_128_32(rst=RST, dc=DC, sclk=18, din=25, cs=22)
# Initialize library.
disp.begin()
# Clear display.
disp.clear()
disp.display()
# Create blank image for drawing.
# Make sure to create image with mode '1' for 1-bit color.
width = disp.width
height = disp.height
image = Image.new('1', (width, height))
# Get drawing object to draw on image.
draw = ImageDraw.Draw(image)
# Draw a black filled box to clear the image.
draw.rectangle((0,0,width,height), outline=0, fill=0)
# Draw some shapes.
# First define some constants to allow easy resizing of shapes.
padding = -2
top = padding
bottom = height-padding
# Move left to right keeping track of the current x position for drawing shapes.
x = 0
# Load default font.
font = ImageFont.load_default()
# Alternatively load a TTF font. Make sure the .ttf font file is in the same directory as the python script!
# Some other nice fonts to try: http://www.dafont.com/bitmap.php
# font = ImageFont.truetype('Minecraftia.ttf', 8)
while True:
# Draw a black filled box to clear the image.
draw.rectangle((0,0,width,height), outline=0, fill=0)
# Shell scripts for system monitoring from here : https://unix.stackexchange.com/questions/119126/command-to-display-memory-usage-disk-usage-and-cpu-load
cmd = "hostname -I |cut -f 2 -d ' '"
IP = subprocess.check_output(cmd, shell = True )
cmd = "top -bn1 | grep load | awk '{printf \"CPU Load: %.2f\", $(NF-2)}'"
CPU = subprocess.check_output(cmd, shell = True )
cmd = "free -m | awk 'NR==2{printf \"Mem: %s/%sMB %.2f%%\", $3,$2,$3*100/$2 }'"
MemUsage = subprocess.check_output(cmd, shell = True )
cmd = "df -h | awk '$NF==\"/\"{printf \"Disk: %d/%dGB %s\", $3,$2,$5}'"
Disk = subprocess.check_output(cmd, shell = True )
cmd = "vcgencmd measure_temp |cut -f 2 -d '='"
temp = subprocess.check_output(cmd, shell = True )
# Write two lines of text.
draw.text((x, top), "IP: " + str(IP,'utf-8'), font=font, fill=255)
draw.text((x, top+8), str(CPU,'utf-8') + " " + str(temp,'utf-8') , font=font, fill=255)
draw.text((x, top+16), str(MemUsage,'utf-8'), font=font, fill=255)
draw.text((x, top+25), str(Disk,'utf-8'), font=font, fill=255)
# Display image.
disp.image(image)
disp.display()
time.sleep(.1)
#include <SoftReset.h>
#include "U8glib.h"
#include "SoftwareSerial.h"
#include <MemoryFree.h>
#include <avr/sleep.h>
#define nextButton 7 //define the pin numbers for the buttons
#define previousButton 5
#define menuButton 4
#define mot 9
#define buzz A3
SoftwareSerial bluetooth(2,3); //Use software serial for bluetooth
const unsigned char PROGMEM ICON_BITMAP_1[] =
{ //Android Logo
0x00,0x00,
0x00,0x00,
0x04,0x40,
0x07,0xc0,
0x0f,0xe0,
0x0b,0xa0,
0x1f,0xf0,
0x00,0x00,
0x5f,0xf4,
0x5f,0xf4,
0x5f,0xf4,
0x5f,0xf4,
0x1f,0xf0,
0x0c,0x60,
0x0c,0x60,
0x00,0x00
};
const unsigned char PROGMEM ICON_BITMAP_20[] =
{ //chat
0x00,0x00,
0x00,0x00,
0x3f,0xf8,
0x40,0x04,
0x40,0x04,
0x40,0x04,
0x40,0x04,
0x49,0x24,
0x40,0x04,
0x40,0x04,
0x40,0x04,
0x3f,0xc8,
0x00,0x28,
0x00,0x18,
0x00,0x08,
0x00,0x00
};
const unsigned char PROGMEM ICON_BITMAP_65[] =
{ //bar signal
0x00,0x00,
0x00,0x00,
0x3f,0xe0,
0x10,0x40,
0x08,0x80,
0x05,0x00,
0x02,0x00,
0x02,0x00,
0x02,0x00,
0x00,0x0c,
0x00,0x6c,
0x03,0x6c,
0x1b,0x6c,
0x1b,0x6c,
0x00,0x00,
0x00,0x00
};
int i,c=0,t=0;
boolean clockUp = true;
boolean menuShow = false;
boolean selectButtonbool = false;
boolean newMessage = false;
boolean newCall = false;
boolean newCallR = false;
boolean newNote = false;
boolean newBuzz = false;
byte hours = 0;
byte minutes = 0;
byte seconds = 0;
byte day = 0;
byte date = 0;
byte month = 0;
int year = 0;
int k,j,n1,n2,n3,n4,n5,n6,n7,n8,N1,N2,N3,N4,N5,N6,N7,N8 = 0;
float x1,x2,ans = 0.0;
char DateBuffer[30];
char* TimeStorage [6];
char* vout;
String monthw;
String number;
String numberR;
String NoteS;
String message; //Variable for SMS messages
String blReceived; //Storage for strings received from bluetooth
char msg[150]; //Char array for SMS
char numb[15];
char numbR[15];
char note[300];
String op[4]={"+","-","*","/"};
byte menuSelection = 0; //Menu
byte menuSelections = 0; //Settings
byte menuSelectiona = 0; //Apps
byte len; //Length of message
byte len1;
byte len2;
byte l;
static unsigned long lastTick = 0;
//U8GLIB_SSD1306_ADAFRUIT_128X64 u8g(U8G_I2C_OPT_NO_ACK|U8G_I2C_OPT_FAST);
//U8GLIB_SSD1306_128X64 u8g(U8G_I2C_OPT_DEV_0|U8G_I2C_OPT_NO_ACK|U8G_I2C_OPT_FAST); // I2C / TWI
U8GLIB_SSD1306_128X64 u8g(U8G_I2C_OPT_NO_ACK|U8G_I2C_OPT_FAST);
//U8GLIB_SH1106_128X64_2X u8g(13, 11, 10, 9,8); // SW SPI Com: SCK = 13, MOSI = 11, CS = 10, A0 = 9, RST = 8
void setup(void) {
// flip screen, if required
//u8g.setRot180();
pinMode(nextButton,INPUT); //Set digital pins as inputs
pinMode(previousButton,INPUT);
pinMode(menuButton,INPUT);
pinMode(mot,OUTPUT);
pinMode(buzz,OUTPUT);
Serial.begin(9600);
bluetooth.begin(9600);
digitalWrite(nextButton,HIGH); //Enable internal pull up on all buttons
digitalWrite(previousButton,HIGH);
digitalWrite(menuButton,HIGH);
digitalWrite(mot,HIGH);
delay(500);
digitalWrite(mot,LOW);
drawStartUp();
delay(4000);
}//end of setup
void loop() {
int k,j,n1,n2,n3,n4,n5,n6,n7,n8,N1,N2,N3,N4,N5,N6,N7,N8 = 0;
float x1,x2,ans = 0.0;
t++;
if(t>160)
{
sleep();
}
if(digitalRead(menuButton)==LOW)
t=0;
if(bluetooth.available() > 0 /*&& bluetooth.find("(")*/)
{
blReceived = bluetooth.readString();
if(blReceived.startsWith("1")) //1 is the preamble date
{
digitalWrite(mot,HIGH);
delay(1000);
digitalWrite(mot,LOW);
seconds++;
blReceived.toCharArray(DateBuffer,blReceived.length()+1);
vout = strtok(DateBuffer,",");
for(int i=0;i<=6;i++)
{
//if(TimeStorage[i] = NULL)
//{Serial.println("Exited Loop");
// break;}
TimeStorage[i] = strtok(NULL,",");
delay(10);
}
//int example = bluetooth.parseInt();
day = atoi(TimeStorage[0] - 1);
date = atoi(TimeStorage[1]);
month = atoi(TimeStorage[2]);
year = atoi(TimeStorage[3]);
hours = atoi(TimeStorage[4]);
minutes = atoi(TimeStorage[5]);
seconds = atoi(TimeStorage[6]);
blReceived="";
t=0;
}
else if (blReceived.startsWith("2"))
{
digitalWrite(mot,HIGH);
delay(1000);
digitalWrite(mot,LOW);
seconds++;
newMessage = true;
message = blReceived;
//sms();
//delay(300000);
blReceived="";
t=0;
}
else if (blReceived.startsWith("3"))
{
digitalWrite(mot,HIGH);
delay(1000);
digitalWrite(mot,LOW);
seconds++;
newCall = true;
number = blReceived;
//num();
//delay(300000);
blReceived="";
t=0;
}
else if (blReceived.startsWith("4"))
{
digitalWrite(mot,HIGH);
delay(1000);
digitalWrite(mot,LOW);
newCallR = true;
numberR = blReceived;
t=0;
u8g.firstPage();
do
{
u8g.setFont(u8g_font_unifont);
u8g.setPrintPos(0,20);
u8g.print("Calling...");
u8g.setPrintPos(0,40);
u8g.print(numberR);
len2 = numberR.length();
number.toCharArray(numbR, len2+1);
//Serial.println(len2);
if(len2<15)
{
//Serial.println("If");
for (int i = 0;(i-1)<len2;i++)
{
//Serial.println("Enter for loop");
u8g.setPrintPos(i*8,30);
u8g.print(numbR[i-15]);
delay(10);
if(numbR[i-16] == '\0')
{
//Serial.println("Break!!");
break;
//delay(3000);
}
}
}
}
while (u8g.nextPage());
blReceived="";
delay(15000);
seconds=seconds+15;
newCallR = false;
}
else if (blReceived.startsWith("5"))
{
digitalWrite(mot,HIGH);
delay(1000);
digitalWrite(mot,LOW);
seconds++;
newNote = true;
NoteS = blReceived;
//notes();
//delay(300000);
blReceived="";
t=0;
}
else if (blReceived.startsWith("6"))
{
newBuzz = true;
Buzz();
blReceived="";
t=0;
}
/*Serial.println(day-1);
Serial.println(date);
Serial.println(month);
Serial.println(year);
Serial.println(hours);
Serial.println(minutes);
Serial.println(seconds);*/
} //end of if for datetime
/*Serial.println(day-1);
Serial.println(date);
Serial.println(month);
Serial.println(year);
Serial.println(hours);
Serial.println(minutes);
Serial.println(seconds);*/
/*else if(bluetooth.available() > 0 && bluetooth.find("CMD")==true)
{
Serial.println("ENTERED MESSAGE");
message = bluetooth.readString();
Serial.println(message);
//delay(300000);
}
*/
if(digitalRead(previousButton)==LOW && digitalRead(nextButton)==LOW) //button is activated
{
seconds=seconds+4;
if(menuShow == false) //To toggle the menu states
{
menuShow = true;
delay(100);
menu(); //Get back the menu selection number
if(menuSelection == 4)
{
seconds=seconds+4;
delay(100);
menuSelection = 0;
while(digitalRead(menuButton)== HIGH)
{
HA();
delay(10);
}
}
if(menuSelection == 3)
{
seconds=seconds+4;
settings();
if(menuSelections == 2)
{
seconds=seconds+4;
delay(100);
menuSelections=0;
delay(100);
while(digitalRead(menuButton)== HIGH)
{
notice();
}
delay(100);
}
if(menuSelections == 3)
{
seconds=seconds+4;
delay(100);
menuSelections=0;
while(digitalRead(menuButton)==HIGH)
{
torch();
delay(10);
}
}
if(menuSelections == 4)
{
seconds=seconds+4;
delay(100);
menuSelections=0;
while(digitalRead(menuButton)==HIGH)
{
bluetooth.write("1");
delay(1000);
bluetooth.write("");
}
}
bluetooth.write("");
bluetooth.write("2");
bluetooth.write("");
}
if(menuSelection == 2)
{
seconds=seconds+4;
apps();
if(menuSelectiona == 2)
{
seconds=seconds+4;
delay(100);
menuSelectiona = 0;
while(digitalRead(menuButton)==HIGH)
{
Calc();
}
bluetooth.write("");
}
if(menuSelectiona == 3)
{
seconds=seconds+4;
delay(100);
menuSelectiona = 0;
while(digitalRead(menuButton)== HIGH)
{sms();}
delay(100);
}
if(menuSelectiona == 4)
{
seconds=seconds+4;
delay(100);
menuSelectiona = 0;
while(digitalRead(menuButton)== HIGH)
{call();}
delay(100);
}
}
}
if(menuShow == true)
{
menuShow = false;
delay(100);
}
}//end of if
advanceTime();
delay(30);
}//end of loop
void sleep()
{
u8g.firstPage();
do{}
while(u8g.nextPage());
}
void advanceTime()
{
if(millis()-lastTick>950) //somehow
{
lastTick = millis();
seconds++;
}
if (seconds > 59)
{
minutes++;
seconds = 0;
}
if (minutes >59)
{
hours++;
minutes = 0;
}
if (hours > 23)
{
hours = 0;
minutes = 0;
date+=1;
}
draw();
}
//*****------------------U8Glib Functions------------------*****
void HA()
{
u8g.firstPage();
do {
bluetooth.write("3");
u8g.setFont(u8g_font_unifont);
u8g.setPrintPos(0,10);
u8g.print("Home Automation");
u8g.setFont(u8g_font_unifont);
u8g.setPrintPos(30,10);
u8g.print("In Development");
bluetooth.write("");
} while( u8g.nextPage() );
}
void Buzz()
{
while(c<5)
{
for(i=1;i<256;i++)
{
analogWrite(buzz,i);
delay(3.92);
}
for(i=256;i>0;i--)
{
analogWrite(buzz,i);
delay(3.92);
}
c++;
}
c=0;
newBuzz=false;
}
void drawStartUp()
{
u8g.firstPage();
do
{
//u8g_prepare();
u8g.setColorIndex(0);
u8g.drawBox(0,0,127,63);
u8g.setColorIndex(1);
u8g.setFont(u8g_font_7x14r);
u8g.setPrintPos(5,10);
u8g.print("Developed By:-");
u8g.setFont(u8g_font_fur17r);
u8g.setPrintPos(10,38);
u8g.print("USER");
u8g.setFont(u8g_font_7x14r);
u8g.setPrintPos(5,62);
u8g.print("V402");
}
while(u8g.nextPage());
} //end of drawStartUp
void menu()
{
u8g.setColorIndex(1);
//u8g.drawCircle(20,20,14);
menuSelection = 1;
while(digitalRead(menuButton) == HIGH)
{
if(digitalRead(nextButton) == LOW)
{
delay(20);
menuSelection++;
delay(50);
}
if(digitalRead(previousButton) == LOW)
{
delay(20);
menuSelection--;
delay(50);
}
if(menuSelection > 4)
{menuSelection = 1;}
if(menuSelection < 1)
{menuSelection = 4;}
//draw picture here
drawMenu();
delay(50); //For debouncing
//draw menus here
}//end of while loop
}//end of menu
void drawMenu()
{
u8g.firstPage();
do
{
u8g.setFont(u8g_font_6x10r);
u8g.setPrintPos(30,8);
u8g.print("--- Menu ---");
//u8g.setPrintPos(0,10);
//u8g.print(menuSelection);
u8g.drawFrame(0,(menuSelection*13)-3,128,13); //Box height is 13 pixels
u8g.drawLine(0,10,128,10);
//Draw menu options
u8g.drawStr(3,20,"Return");
u8g.drawStr(3,20+13,"Apps");
u8g.drawStr(3,20+13+13,"Settings");
u8g.drawStr(3,20+13+13+13,"Home Auto(Beta)");
//u8g.drawStr(3,20+13+13+13,"More");
}
while(u8g.nextPage());
}
void apps()
{
u8g.setColorIndex(1);
//u8g.drawCircle(20,20,14);
menuSelectiona = 1;
delay(200);
while(digitalRead(menuButton) == HIGH)
{
if(digitalRead(nextButton) == LOW)
{
delay(20);
menuSelectiona++;
Serial.println("Up");
delay(50);
}
if(digitalRead(previousButton) == LOW)
{
delay(20);
menuSelectiona--;
delay(50);
}
if(menuSelectiona > 4)
{menuSelectiona = 1;}
if(menuSelectiona < 1)
{menuSelectiona = 4;}
//draw picture here
drawApps();
delay(50); //For debouncing
}//end of while loop
}
void notice()
{
u8g.firstPage();
do
{
u8g.setFont(u8g_font_6x10r);
//u8g.print(NoteS);
l = NoteS.length();
NoteS.toCharArray(note, l+1);
//Serial.println(len);
if(l>0)
{
for(i=0;i<20;i++)
{
u8g.setPrintPos(i*6,8);
u8g.print(note[i]);
delay(10);
}
}
if(l>20)
{
for(i=20;i<40;i++)
{
u8g.setPrintPos((i-20)*6,17);
u8g.print(note[i]);
delay(10);
}
}
if(l>40)
{
for(i=40;i<60;i++)
{
u8g.setPrintPos((i-40)*6,26);
u8g.print(note[i]);
delay(10);
}
}
if(l>60)
{
for(i=60;i<80;i++)
{
u8g.setPrintPos((i-60)*6,35);
u8g.print(note[i]);
delay(10);
}
}
if(l>80)
{
for(i=80;i<100;i++)
{
u8g.setPrintPos((i-80)*6,43);
u8g.print(note[i]);
delay(10);
}
}
if(l>100)
{
for(i=100;i<120;i++)
{
u8g.setPrintPos((i-100)*6,51);
u8g.print(note[i]);
delay(10);
}
}
if(l>120)
{
for(i=120;i<140;i++)
{
u8g.setPrintPos((i-120)*6,59);
u8g.print(note[i]);
delay(10);
}
}
}
while (u8g.nextPage());
delay(30);
newNote = false;
}
void torch()
{
u8g.firstPage();
do{u8g.drawBox(0,0,127,63);}
while(u8g.nextPage());
}
void drawApps()
{
u8g.firstPage();
do
{
u8g.setFont(u8g_font_6x10r);
u8g.setPrintPos(5,8);
u8g.print("--- Applications ---");
//u8g.setPrintPos(0,10);
//u8g.print(menuSelection);
u8g.drawFrame(0,(menuSelectiona*13)-3,128,13); //Box height is 13 pixels
u8g.drawLine(0,10,128,10);
//Draw menu options
u8g.drawStr(3,20,"Return");
u8g.drawStr(3,20+13,"CALC");
u8g.drawStr(3,20+13+13,"SMS");
u8g.drawStr(3,20+13+13+13,"CALLS");
//u8g.drawStr(3,20+13+13+13,"More");
}
while(u8g.nextPage());
}
void settings()
{
u8g.setColorIndex(1);
//u8g.drawCircle(20,20,14);
menuSelections = 1;
delay(200);
while(digitalRead(menuButton) == HIGH)
{
if(digitalRead(nextButton) == LOW)
{
delay(20);
menuSelections++;
Serial.println("Up");
delay(50);
}
if(digitalRead(previousButton) == LOW)
{
delay(20);
menuSelections--;
delay(50);
}
if(menuSelections > 4)
{menuSelections = 1;}
if(menuSelections < 1)
{menuSelections = 4;}
//draw picture here
drawSettings();
delay(50); //For debouncing
}//end of while loop
}
void sms()
{
u8g.firstPage();
do
{
u8g.setFont(u8g_font_unifont);
u8g.setPrintPos(0,10);
u8g.print(message);
len = message.length();
message.toCharArray(msg, len+1);
//Serial.println(len);
if(len>16)
{
//Serial.println("If");
for (int i = 0;(i-1)<len;i++)
{
//Serial.println("Enter for loop");
u8g.setPrintPos(i*8,30);
u8g.print(msg[i+16]);
delay(10);
if(msg[i+17] == '\0')
{
//Serial.println("Break!!");
break;
//delay(3000);
}
}
}
if(len>32)
{
//Serial.println("If");
for (int i = 0;(i-1)<len;i++)
{
//Serial.println("Enter for loop");
u8g.setPrintPos(i*8,50);
u8g.print(msg[i+32]);
delay(10);
if(msg[i+33] == '\0')
{
//Serial.println("Break!!");
break;
//delay(3000);
}
}
}
}
while (u8g.nextPage());
delay(30);
newMessage = false;
}
void call()
{
u8g.firstPage();
do
{
u8g.setFont(u8g_font_unifont);
u8g.setPrintPos(0,10);
u8g.print(number);
len1 = number.length();
number.toCharArray(numb, len1+1);
//Serial.println(len1);
if(len1<15)
{
//Serial.println("If");
for (int i = 0;(i-1)<len1;i++)
{
//Serial.println("Enter for loop");
u8g.setPrintPos(i*8,30);
u8g.print(numb[i-15]);
delay(10);
if(numb[i-16] == '\0')
{
//Serial.println("Break!!");
break;
//delay(3000);
}
}
}
}
while (u8g.nextPage());
delay(30);
newCall = false;
}
void drawSettings()
{
u8g.firstPage();
do
{
u8g.setFont(u8g_font_6x10r);
u8g.setPrintPos(15,8);
u8g.print("--- Settings ---");
//u8g.setPrintPos(0,10);
//u8g.print(menuSelection);
u8g.drawFrame(0,(menuSelections*13)-3,128,13); //Box height is 13 pixels
u8g.drawLine(0,10,128,10);
//Draw menu options
u8g.drawStr(3,20,"Return");
u8g.drawStr(3,20+13,"Notes");
u8g.drawStr(3,20+13+13,"Torch");
u8g.drawStr(3,20+13+13+13,"Find My Phone");
}
while(u8g.nextPage());
}
void CalcPrintdata()
{
u8g.setPrintPos(50,25);
u8g.print(n3);
u8g.setPrintPos(40,25);
u8g.print(n4);
u8g.setPrintPos(30,25);
u8g.print(n5);
u8g.setPrintPos(20,25);
u8g.print(n6);
u8g.setPrintPos(60,25);
u8g.print(".");
u8g.setPrintPos(70,25);
u8g.print(n7);
u8g.setPrintPos(80,25);
u8g.print(n8);
u8g.setPrintPos(3,37);
u8g.print(op[k]);
u8g.setPrintPos(50,37);
u8g.print(N3);
u8g.setPrintPos(40,37);
u8g.print(N4);
u8g.setPrintPos(30,37);
u8g.print(N5);
u8g.setPrintPos(20,37);
u8g.print(N6);
u8g.setPrintPos(60,37);
u8g.print(".");
u8g.setPrintPos(70,37);
u8g.print(N7);
u8g.setPrintPos(80,37);
u8g.print(N8);
u8g.setPrintPos(5,46);
u8g.print("---------------");
u8g.setPrintPos(5,54);
u8g.print(ans);
}
void Calc()
{
u8g.firstPage();
do{
u8g.setFont(u8g_font_unifont);
u8g.setPrintPos(0,10);
u8g.print("Calculator:-");
if(digitalRead(previousButton) == LOW)
{
j++;
delay(300);
if(j>12)
j = 0;
}
if(digitalRead(nextButton)==LOW && digitalRead(previousButton)==LOW)
{
j=13;
delay(300);
}
if(j==0)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
n6++;
delay(300);
}
if(n6>9)
n6=0;
}
if(j==1)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
n5++;
delay(300);
}
if(n5>9)
n5=0;
}
if(j==2)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
n4++;
delay(300);
}
if(n4>9)
n4=0;
}
if(j==3)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
n3++;
delay(300);
}
if(n3>9)
n3=0;
}
if(j==4)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
n7++;
delay(300);
}
if(n7>9)
n7=0;
}
if(j==5)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
n8++;
delay(300);
}
if(n8>9)
n8=0;
}
if(j==6)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
k++;
delay(300);
}
if(k>3)
k=0;
}
if(j==7)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
N6++;
delay(300);
}
if(N6>9)
N6=0;
}
if(j==8)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
N5++;
delay(300);
}
if(N5>9)
N5=0;
}
if(j==9)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
N4++;
delay(300);
}
if(N4>9)
N4=0;
}
if(j==10)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
N3++;
delay(300);
}
if(N3>9)
N3=0;
}
if(j==11)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
N7++;
delay(300);
}
if(N7>9)
N7=0;
}
if(j==12)
{
CalcPrintdata();
if(digitalRead(nextButton) == LOW)
{
N8++;
delay(300);
}
if(N8>9)
N8=0;
}
if(j==13)
{
CalcPrintdata();
x1 = n6*1000+n5*100+n4*10+n3+n7*0.1+n8*0.01;
x2 = N6*1000+N5*100+N4*10+N3+N7*0.1+N8*0.01;
if(k==0)
{
ans = x1 + x2;
}
if(k==1)
{
ans = x1 - x2;
}
if(k==2)
{
ans = x1 * x2;
}
if(k==3)
{
ans = x1 / x2;
}
}
}
while(u8g.nextPage());
}
void draw()
{
u8g.firstPage();
do
{
if(t<160)
{
//u8g.drawLine(0,15,128,15);
u8g.setFont(u8g_font_7x14r);
u8g.drawStr(3,14,"V402");
u8g.setFont(u8g_font_fur17r);
String strDate = String("");
char time[10]; //9
if (hours < 10)
strDate += "0";
strDate += hours;
strDate += ":";
if (minutes < 10)
strDate += "0";
strDate += minutes;
strDate += ":";
if (seconds < 10)
strDate += "0";
strDate += seconds;
strDate.toCharArray(time,10); //9
time[12] = 0x00; //9
u8g.drawStr(20,40,time);
switch (month)
{
case 01:
monthw = "January";
break;
case 02:
monthw = "February";
break;
case 03:
monthw = "March";
break;
case 04:
monthw = "April";
break;
case 05:
monthw = "May";
break;
case 06:
monthw = "June";
break;
case 07:
monthw = "July";
break;
case 8:
monthw = "August";
break;
case 9:
monthw = "September";
break;
case 10:
monthw = "October";
break;
case 11:
monthw = "November";
break;
case 12:
monthw = "December";
break;
}
u8g.setFont(u8g_font_6x10r); //Smaller font for date
//u8g.setFont(u8g_font_7x14r);
u8g.setPrintPos(0,55);
u8g.print(date);
u8g.setPrintPos(15,55);
u8g.print("/");
/*switch (date)
{
case 1:
u8g.print("st");
break;
case 2:
u8g.print("nd");
break;
case 3:
u8g.print("rd");
break;
default:
u8g.print("th");
break;
}
*/
u8g.setPrintPos(27,55);
u8g.print(month); //formerly monthw
u8g.setPrintPos(35,55);
u8g.print("/");
u8g.setPrintPos(43,55);
u8g.print(year);
//u8g.drawBitmapP(110,1,1,8,IMG_indicator_msg);
u8g.drawBitmapP( 110, 1, 2, 16, ICON_BITMAP_65);
if(newNote == true)
{
u8g.drawBitmapP(88,45,2,16,ICON_BITMAP_20);
}
if(newMessage == true)
{
u8g.drawBitmapP(110,45,2,16,ICON_BITMAP_1);
}
if(newCall == true)
{
u8g.drawBitmapP(110,45,2,16,ICON_BITMAP_1);
}
}
}
while(u8g.nextPage());
}//end of draw
