Measure Distance Using Ultrasonic Sensor | Pi4J | JAVA | Raspberry Pi

Ultrasonic ranging module HC - SR04 provides 2cm - 400cm non contact measurement function, the ranging accuracy can reach to 3mm. The modules includes ultrasonic transmitters, receiver and control circuit. The basic principle of work:

(1) Using IO trigger for at least 10us high level signal,

(2) The Module automatically sends eight 40 kHz and detect whether there is a pulse signal back.

(3) IF the signal back, through high level , time of high output IO duration is the time from sending ultrasonic to returning.

Intro visual Source: http://bit.ly/2iJ1vAI

---------------------------------------------------------------------------------------------------

Links : Java Application on Pi Playlist: http://bit.ly/2iJ1vAI

Schematic : http://bit.ly/2iJ1vAI

Pi4J GPIO Numbering : http://bit.ly/2iJ1vAI

Download Pi4J Library : http://bit.ly/2iJ1vAI

Code : http://bit.ly/2iJ1vAI
