Learning Logic Gates
Small program/game in python to show how logic gates work through the design and resolution of small circuits. Graphical environment designed in pygame.
Valid for python 2 and pyton 3.
Options to save and reload the work done.
Allows to show the solution of the created circuits and warns in case of errors such as coxion failures between circuit elements.
Detailed help in the "help" menu of the program (and in the code comments).
Code and more details on the project web site
https://github.com/inopya/Aprendizaje_puertas_logicas
Supplies
- computer
- python
- pygame
Examples
Sample circuit
