LED Dome Light Upgrade

I hate incandescent bulbs! I also don't like ordering LED bulbs online. So I am lucky enough to have a Frys near by. I picked up about 5 epoxy sealed 12v LED SMD

• Clear rubber/soft plastic bumpers (optional)
• Linrose LED Modules (BIM1220W-White) [or any color u want/find]
• Cut off disc/wheel or small hack saw (I like my Dremel)

• Small screwdriver set
• Plastic wedge (I used my short finger nails)
• Side cutters
• Solder iron
• Elec-Solder wire

I don' have a pic before the soldered finished product. Sorry.

• wedge / pry
• most likely clips on the sides (squeeze or compress)
• slowly pull to the direction of least resistance
• find wire harness (small flat head screw driver for tab [push end closest to you down] if you have clumsy fingers like mine) pull to separate connection

+- 90% of vehicles after 2000 wont have screws holding the dome light.

It is critical you determine what steps to take here! Not all cars are the same.

All I had to do was remove the clear plastic light diffuser to remove the bulb and place my LED module. Had my dome light been more shallow I would have needed to modify the bulb holder to accommodate the plastic light diffuser.

• Find the Positive terminal (mark it)
• Run your wiring (I had to do a little cutting as pointed out in the picture)
• Temporarily secure the LED wire to your terminals and recheck you have power to the LED
• Solder your joints

Confirm joints are good, check fitment of plastic light diffuser, and retest power to LED

• Connect Harness
• Check functionality (On/doorOn)
• Push back into place as you did when removing (path of least resistance)
• May have to give good kick (push) to get the clips to hold it tight against the headliner
• Re-check functionality (On/doorOn)

All Done!
