LED STRIP CONTROL FOR TVS V1

Many times we have had the problem that our old televisions are damaged by the lighting tube and today we already have the LED strips to be able to replace them. Today we will make this very easy system that can control LED strips up to 1A with power control at 5V

Here we will see the schematic diagram made in the easyeda software with all the electronic components and their respective values.

This circuit is powered with 12VDC and the control with 5VDC with indicator LEDs that are at these voltages that come from the electronic card and we can control 2 independent LED strips, a very easy circuit to make and with few electronic components.

• 1 DIODE 1N4007
• 2 RESISTORS 1K 1/4W
• 1 RESISTOR 1.5K 1/4W
• 2 DIODES LEDS 3MM RED AND YELLOW
• 1 TRANSISTOR TIP31C
• 1 ESPADIN 8 PINS

• VIN 12VDC
• V control 5VDC
• V tira led 12VDC
• I CONTROL TIRA LED 1A

This project was made in the Easyeda software as we can see the tracks and the 3D image of the project working perfectly are no difficulty
