How to Cast Hollow Parts in a Mold Using Wax, Clay, Epoxy and Cement

Learn the easiest method for duplicate your hollow parts!

First Remove the hollow master from the mold.
The center of the hollow piece was also molded and used.

Clear Casting Plastic is used as an example of a thin slow curing casting material.

The steps include:

1. Prepare the mold with mold release.
2. Place toothpicks in the mold to hold the mold core exactly in the center of the mold making sure there are voids all around the core.
3. Mix the Clear Casting Plastic 1 part A to 1 part B by weight or volume.
4. Pour the Clear Casting Plastic and wait 24hrs for it to cure.
5. Remove the part from the mold.

Wax Is used as an example of a thin quick curing casting material.

The steps include:

1. Chill the mold (preferably in a freezer).
2. Melt the wax and wait for its temperature to fall below 170F.
3. Pour the wax into the mold slushing it around covering the mold evenly.
4. Wait for the wax to cool.
5. Remove the part from the mold.

Clay is used as an example of a semi-solid casting material.

The steps include:

1. Prepare the mold with mold release.
2. Push the clay into the mold.
3. Remove the piece from the mold.
4. Smooth out the imperfections.
5. Wait for it to solidify and then fire the part in a kiln.

ComposiStone is used as an example of a thick casting material.

The steps include:

1. Prepare the mold with mold release.
2. Mix the ComposiStone 1 part water to 2.5 parts ComposiStone by volume.
3. Pour the ComposiStone and brush it around with your hand getting all sides evenly.
4. Wait 1 hour for it to solidify.
5. Remove the part from the mold and let sit for 1 day before painting.
