How to Get More Functionality Out of Your Arduino Zero
In this Instructable we look at how to get more functionality out of your Arduino Zero board, including getting access to 6 additional digital pins and adding some more flexibility to the Zero's communication capabilities.
//**********************Arduino Code from the video*********************
//This code is free to use and modify at your own risk
bool tog = false; //used to toggle LEDs on and off
void setup() {
pinMode(38,OUTPUT); //This is the pin labeled "ATN"
pinMode(22,OUTPUT); //This is MISO pin on ICSP header
pinMode(20,OUTPUT); //This is SDA pin
SerialUSB.begin(57600); //this is the native USB port
Serial.begin(57600); //this is the programming port
Serial1.begin(57600); //this is for pins D0 and D1
}
void loop() {
if(tog) { //set each of the pins to high to turn LEDs on
digitalWrite(38,HIGH);
digitalWrite(22,HIGH);
digitalWrite(20,HIGH);
tog = false;
}
else { //set each pin to low to turn them off
digitalWrite(38,LOW);
digitalWrite(22,LOW);
digitalWrite(20,LOW);
tog = true;
}
delay(1500); //delsy for 1.5 seconds
}
