Handle for Vernier Caliper Mitutoyo

by rsave in Workshop > Tools

198 Views, 0 Favorites, 0 Comments

Handle for Vernier Caliper Mitutoyo

Vernier Caliper MITUTOYO - handle from print3D

Look my instruct video! ;)

Download Files

1. f3d for fusion360

2. stl for your slicer

3. package winrar

Slicer and Print


- slicer your favorite prog

- printing 3d

Neodymium Magnetic

block magnetic.jpg

Mount neodymium magnetic in workshop handle.

box 20x10x2

Screw the Holder to the Wall


mount your handle

Good Job! Hang Your Tools.

caliper 2.jpg

Magnetic Click ;)
