Hacked!!! Convert Any IR Remote Into RF
![instructable.png](/proxy/?url=https://content.instructables.com/FCC/6GLE/L0LIG54W/FCC6GLEL0LIG54W.png&filename=instructable.png)
In this episode of HACKED! I will show you how I used the popular 433mhz rf module to control the home theater wirelessly. You can convert an IR remote into one that uses radio frequency (RF) that doesn't require line of sight and which can work over great distances and even through walls.
Watch the Video!
![Hacked!!! Convert Any IR Remote Into RF](/proxy/?url=https://content.instructables.com/FE2/PRQA/L0LIG589/FE2PRQAL0LIG589.jpg&filename=Hacked!!! Convert Any IR Remote Into RF)
Make sure to watch the video. It will give you pretty much all the information you need. During the next steps though, I will present you some additional information.
Order Your Components!
![Ir.00_00_38_09.Still003.png](/proxy/?url=https://content.instructables.com/FNV/KRXV/L0LIG5WA/FNVKRXVL0LIG5WA.png&filename=Ir.00_00_38_09.Still003.png)
Parts list (affiliate links):
Amazon.in:
IR Reciever: https://amzn.to/3u7fjLv
433mhz RF Module: https://amzn.to/3u9CJzQ
Build the Circuit!
![Ir.00_01_34_14.Still002.png](/proxy/?url=https://content.instructables.com/FHC/Z6KA/L0LIGE8L/FHCZ6KAL0LIGE8L.png&filename=Ir.00_01_34_14.Still002.png)
Here you can find the schematic of the project.
Downloads
Success!
![Ir.00_01_52_14.Still002.png](/proxy/?url=https://content.instructables.com/F4D/LHMF/L0LIG64M/F4DLHMFL0LIG64M.png&filename=Ir.00_01_52_14.Still002.png)
You did it! You just convert your own ir remote into rf
