Gesture Control Robot
![IMG-20170206-WA0024.jpg](/proxy/?url=https://content.instructables.com/FZX/3DFV/IZQA4XWI/FZX3DFVIZQA4XWI.jpg&filename=IMG-20170206-WA0024.jpg)
![IMG-20170206-WA0025.jpg](/proxy/?url=https://content.instructables.com/F8M/FNKW/IZQA4XWJ/F8MFNKWIZQA4XWJ.jpg&filename=IMG-20170206-WA0025.jpg)
![Gesture Control Robot](/proxy/?url=https://content.instructables.com/F6G/JR24/IZQAERGI/F6GJR24IZQAERGI.jpg&filename=Gesture Control Robot)
A gesture control is an Accelerometer based robotic vehicle which is capable to detect the tilt of hand and move according to it, so I named it “Gesture Control Robot”. The main intention of making this project is that to understand the working of accelerometer and Robotics in interesting way. I was inspired to make this project when I saw this project in my college which was made by my senior Mr. Chinmya Sharma.
Circuit Components
For Transmitter Circuit
1. Arduino (any)
2. Accelerometer
3. HT12E IC
4. RF Transmitter
5. Battery
For Receiver Circuit
1. RF Receiver
2. HT12D IC
3. L293D Motor Driver
4. Two DC Geared Motors (12 Volt)
5. Chassis
6. Two Wheels
7. Rechargeable battery (12 Volt)
Transmitter Circuit
![Untitled Sketch 2_bb.png](/proxy/?url=https://content.instructables.com/FS9/OJME/IZQA4XN3/FS9OJMEIZQA4XN3.png&filename=Untitled Sketch 2_bb.png)
Receiver Circuit
![Untitled Sketch 3_bb.png](/proxy/?url=https://content.instructables.com/FDT/134H/IZQA4XOE/FDT134HIZQA4XOE.png&filename=Untitled Sketch 3_bb.png)
Upload the Code
Copy the code from my site
http://clgproject.com/learn/gesture-control-robot
Finish
Just copy and paste the code into arduino.
