DIY SmartPhone Controlled RGB Led WS2812
by BidCZI in Circuits > Arduino
1080 Views, 14 Favorites, 0 Comments
DIY SmartPhone Controlled RGB Led WS2812
![DIY SmartPhone Controlled RGB Led WS2812 | Wifi RGB Led Light](/proxy/?url=https://content.instructables.com/FEM/G2NE/KT37X2CK/FEMG2NEKT37X2CK.jpg&filename=DIY SmartPhone Controlled RGB Led WS2812 | Wifi RGB Led Light)
I am going to show you how to make SmartPhone Control RGB Led WS2812 . You Can change Led Colour , Brightness ,On/Off & also make different designs & patterns.You can use mobile , tablet , pc anyone supporting browser. For this you just need a Nodemcu.
Components Needed
1. NodeMcu
2. RGB WS1812B Led strip
3. Power supply 5 volt
Connection & Assembly
![WS2812Circuit.jpg](/proxy/?url=https://content.instructables.com/FI8/P8KV/KT37X24Y/FI8P8KVKT37X24Y.jpg&filename=WS2812Circuit.jpg)
![WS2812 Solder.jpg](/proxy/?url=https://content.instructables.com/FV7/HB0J/KT37X2AI/FV7HB0JKT37X2AI.jpg&filename=WS2812 Solder.jpg)
![AssemblyWS2812.jpg](/proxy/?url=https://content.instructables.com/FJM/0RBM/KT37X2AH/FJM0RBMKT37X2AH.jpg&filename=AssemblyWS2812.jpg)
You need to connect WS1812B strip as per diagram . To form the triangle cut led strips in 3 equal size i.e. 20 led each. Always cut in the dotted line. Then solder it . Next upload the code to Nodemcu. You need separate power supply 5 volt for Led strip. Check video for details.
Download Code
You can download code here
