DIY Life-Size Phone Controlled BB8 Droid

Today, I'm going to teach you how to build a working, life-sized, phone-controlled Starwars BB-8 droid! In this tutorial, we are only going to use household materials and a little Arduino circuitry.

`

My Christmas Gift For Dad: One of my dad's hobby is being a toy collector (Hot Toys, Enterbay & Etc..). He grew up watching movies from the 80's, including Starwars! He is a really huge Starwars fan. When the Sphero BB8 was announced, he wanted it so badly! The Sphero toy cost $150 online, $210 in our country (Philippines), not to mention that they ran out of stock easily! It's not the typical toy that you would buy impulsively. Knowing with my past experience in building robots, I figured I could build a life-sized version of the Sphero BB8 for less than $100. I also saw this as an opportunity to spend some father-and-son time with him. This is what we ended up building in the week of Christmas! Anyway, my mom and I also got him a Sphero BB8 and used it as our reference for building this project. For him I guess, the best gift was the time we spent building it together.

`

Why Household Materials?

Due to the limitation of materials, I resorted in using the materials around me. (deodorant roll-ons as ball bearings, canvas as fiberglass, Christmas balls as the eye & etc.. ). A lot of people could relate to this. My approach on building the project doesn't require 3D printers, CNCs or Milling Machines!

`

The full video tutorial is finally out! (MUST WATCH!)

RECENT UPDATE: BB8's First Day At The University (v1.0 Demo)

DIY BB8 (v2.0) in Progress Update:

If you liked the video, feel free to subscribe to my YouTube channel - TechBuilder! Also, please don't forget to VOTE! Thank you! ^_^

Step to be written soon!

Here's the list of materials needed for the project! You can click on the link if you prefer to buy online.

____________________________

Robotics & Electronics:

- Arduino Uno

- Pololu Dual VNH5019 Motor Shield

- 2x Pololu (19:1) 37D Metal Gearbox

- HC05 Bluetooth Module

- 4 Cell Lithium Battery Pack (2x)

- Switch, DC Jack, Wires, Solder

BB8's Body:

- Inflatable Beach Ball (Diameter: 50cm)

- Old Newspaper

- Plain Canvas Cloth

- 2 Bottles of PVA Glue (a.k.a Elmer's Glue)

- 1 Bottle of Woodglue

- White, Grey and Orange (Tangerine) Spray Paint

- Roll-on Deodorants

BB8's Head:

- Styrofoam Ball (Diameter: 300mm/ 12 inches)

- Christmas Ball (Size of BB8's Eye)

- WiFi Antenna (Prop Only)

- Cloths Hanger

- Roll-on Deodorants

- White, Grey and Orange (Tangerine) Spray Paint

MISC:

- Superglue

- Neodymium Magnets

The first time I saw (comicon-reel) and heard that they we're going to use a real BB8 robot for the Starwars movie, my initial reaction was; A ball? A ball than spins with a head that stays upright? What kind of sorcery is this?!?!?

`

Aside from being extremely cute, BB8 also has a very intriguing design and build. You just can't stop wondering how this droid works! It really took some advanced engineering and a creative mind to invent such a thing. The idea of how the mechanism works, greatly involves concepts of physics and electronics. It's all about maintaining the right center of gravity. The original BB8 design which was used form the movie, used a hamster wheel design. Basically, there's a two wheeleed robot rolling around inside a sphere. The head stays uprightdue to the presence of magnets.

How The Sphero Version Works: (by: Tested)

In addition, this website explains really well, how BB8 works! (http://www.howbb8works.com/)

Pump enough air until you reach the maximum diameter of your beach ball (50cm).

We will use PVA glue (Elmer's glue) as our paper binder/ hardener. Mix 2 part water to 1 part PVA glue.

Gather a bunch of old newspapers. Align them carefully and cut them using a cutter knife and a ruler.

Lay strips of newspaper on the surface of the beach ball and brush them with your mixture of glue. We're basically making a huge piñata. We're going to use the beach ball as our mold for the paper mache.

If you're in a hurry, use a blow dryer to speed up the drying process. Or maybe point an electric fan to the paper mache and leave it to dry overnight.

The store, where I buy fiber glass, ran out of supplies. I used plain canvas instead of the fiber glass. The canvas hardens really well and works as a good paper mache. (cloth mache)

It was raining cats and dogs when I reached this step. I took my paper mache indoors and used a fan to try it overnight.

After the canvas mache dries, you may notice there are overlapping sheets of canvas. You can simply plane it off using a sharp cutter blade. Smoother surface = smoother ride!

Let's begin the smoothening process! Get a can of wood putty and carefully apply it on the outer surface of BB8's body. Use an metal applicator to do the job. The putty fills in the gaps. Any excess putty will be removed after the sanding process.

Once the putty dries. Sand the surface of BB8's body. Use a coarse grit (100-400 grit) of sand paper. I used my Makita electric sander to make the job easier.

Download the file package below. I have included a template of BB8's detailed artwork. I had help from my dad to put this up. I'm very bad at drawing. We used videos and images from the net as our reference.

Circular shapes can be achieved by using a compass. While straight lines which falls on the curved surface of the body can be traced with a tailor's tape measure.

Use lots of masking tape to mask the areas that you don't wan't to get paint on. 'The art of masking'.

We painted BB8's body with 3 different colors of spray paint: white, grey and orange.

Once the paint dries, peel the masking tape. Just be careful in peeling! Sometimes, the paint tends to go with the tape.

BB8's head masures 30cm in diameter. Basically it's a semi-circular head with a beveled edge, a little off from the median. Use a trash bin as a stencil, then use a marker to mark your cutout. Use a hacksaw to cut the Styrofoam ball in half (nearly half).

The beveled edge can be achieved by building a makeshift styrofoam hot-wire cutter. I did that by recycling a piece of wood from an old picture frame, which I then used as the base of the stryo cutter. I mounted a metal stand-off at the middle as the pivot for the stryofoam. I mounted another metal stand-off for the hot-wire. The hot-wire can be stripped from a thick insulated wire. I then connected a switch and a 3.7v (18650) lithium-ion battery in series with the hot-wire. Whenever I press the push button switch, the wire heats up. Clean styro cuts for me!

You can reduce weight by hollowing-out the inner portion of the styro ball. You can do that by melting/ burning the styrofoam using a blowtorch or a lighter.

Then again, apply a layer of wood putty on BB8's head, then sand it with sandpaper.

We painted BB8's head with 3 different colors of spray paint: white, grey and orange.

It was Christmas when I reached this step. I grabbed a frosted Christmas ball from our Christmas tree and used it as BB8's eye. I cleared the frosting by wiping it out with Acetone. I painted the inner portion of the ball with black spray paint, leaving the outer portion with a little luster.

Cut a piece of plastic from a plastic cup, and spray it black! Viola!

BB8's has two antennas. We took a WiFi antenna an hot glued it to the head. For the other antenna, we used a white solid wire. I added an MP3 module and a speaker on more Version 2.0.

I used a 1/4" thick MDF wood as the base of the robotic mechanism inside BB8's body.

This is my new thing now. I save tons of money by assembling my own Lithium-ion battery pack. In this project I'm using a 4 cell battery pack. I simply just soldered four 18650 (3.7v 2000mAh) Lithium-ion batteries in series. 18650 rechargeable batteries are very cheap and common nowadays. I made two sets of these and connected them in parallel. I now have a total of 14.4v (4,000mAh)! It also costs less than my Turningy bats!

Mount the metal gearbox together with the brackets on the MDF/ wooden platform. Use nuts & bolts, not glue.

How It Works:

The phone app sends characters via Bluetooth every time you press a button. The Bluetooth module receives the data while the Arduino interprets and processes these data. The Arduino sends signals to the Motor Driver shield to give a go signal for the switching of the motors.

Steps:

1st.) Mount the Arduino to the platform

2nd.) Stack the Motor Driver Shield

3rd.) Connect the left motor's wires to M1A & M1B

4th.) Connect the right motor's wires to M2A & M2B

5th.) Mount The Lithium-Ion Batteries

Here's the Arduino Code. Before you upload the code/ program to your Arduino Uno board, be sure to install the Pololu Motor Driver Library. Also, please do not forget to disconnect the TX-RX lines of the Bluetooth module from the Arduino. This is done to prevent the Bluetooth module from interfering with the Arduino during the programming process.

`

Don't know how to install an Arduino library? Find the instructions here! (click me).

Here's a link to the phone app that I've used. It's named as 'Arduino Bluetooth RC Car'. It's a very simple app to use.

How To Use It:

1.) Download the app form the play store/ itunes.

2.) Launch the app

3.) Open the configure window (wrench icon)

4.) Tap; connect.

5.) Select HC-05 (The name of the Bluetooth module)

6.) The red light should turn green once it establishes BT communication.

Use a hacksaw to cut BB8's body in half.

Roll-on deodorants!

BB8 has a magnetic mechanism that keeps the head upright. He has a Internal and External one. In my design, I hot glued four Roll-on deodorants (as my makeshift rollers) on a round wooden plate. I then attached a servo with two large magnets attached to it. The plate is mounted to the base with four elongated wooden shafts.

Speaker drivers are good sources of strong magnets. I recycled two blown out speakers and extracted the magnets from it.

Make A Delta Roller:

Again, I made a roller set, this time for the outside (BB8's head). I made a delta/ triangular roller set. Then again, I used roll-on deodorants for the makeshift rollers and then I used a light weight plastic shaft to connect three rollers together. The shaft was taken from a plastic segment of a clothes hanger.

Position The Magnets:

Install the half of BB8's body (above the internal mechanism) then throw your magnets where the magnet is located from the other side. Let them attract each. Ta-daaa! You don't have to take measurements in order to find the exact position of the other the magnets from the other end. Finally hot glue the magnets to the Delta Roller and then hot glue the Delta Roller to the Stryofoam head of BB8.

Downloadable MP3 Files:

Find a the lightest MP3 module you can find. Attach a loud but lightweight speakers to the audio output and upload these BB8 audio/ voice files. Download these MP3 files containing BB8's voice. Copy the files to a SD/ Micro SD card, then insert the card to the MP3 module. Now BB8 can talk!

Encapsulate the robotic mechanism and use superglue or wood glue to seal BB8's body together.

Tips:

1.) Temporarily stick strips of ductape while you glue the sections of the ball. The ductape will hold and align the both semicircular spheres as you glue them together

2.) If you're confident with your work and decided never to crack it open again, use some wood putty then sand it off. This will hide the line of your cut. Repaint BB8's body, and it will look like a solid sphere!

Join the official Facebook group of The Builder's Club! Learn and share idea with fellow members who are building a 1:1 scale BB8 droids! (Visit The Page)

In the early stage of testing in my DIY BB8 (v2.0), I tested if the inner and outer magnetic mechanisms work.This is v2.0 of my build. It uses the same materials but uses a different mechanism (single axis orientation). I'm currently remodeling the head to make it lighter. The external head rollers works! Same as my previous build, no 3D printers nor CNCs were used. The body is made with paper mache, deodorant roll-ons & wooden mechanism chassis. Hope this would give motivation and hope to those who are struggling to make theirs work. Never give up! May the force be with you!

`

I'll bring this guy to the mall and make a reaction video.

`

Reaction video coming soon...
