DIY FPGA AmbilightController System

by pinuo in Circuits > Electronics

154 Views, 1 Favorites, 0 Comments

DIY FPGA AmbilightController System


https://twitter.com/bi4wms/status/1330142367249264641?s=20&t=LuJ8iINT9GbTJFmUX6ddKA

Alos some video on twitter, https://twitter.com/bi4wms

It is my long time DIY projects, based on the hdmilight project in github, also I have done some work, design the pcb, interaged the HDMI spliter(support 1080p and 4K), give up Spartarn6 FPGA use Anlogic FPGA, design the 3D printed case, case sticker, CNC case etc.

Supplies

Material

  1. FPGA-ambiController
  2. WS2812/WS2815 led strip
  3. DC power supply

Design the PCBA


design the circuit

Design the 3D Printed, CNC Case


Assemble the System


just one led strip from left bottom
