DIY Easy PCB Holder(easy)
by electronicslifeandmore in Workshop > Tools
739 Views, 2 Favorites, 0 Comments
DIY Easy PCB Holder(easy)
![WIN_20201012_09_42_29_Pro.jpg](/proxy/?url=https://content.instructables.com/FP9/IX4P/KG54C78D/FP9IX4PKG54C78D.jpg&filename=WIN_20201012_09_42_29_Pro.jpg)
![WIN_20201012_09_28_19_Pro.jpg](/proxy/?url=https://content.instructables.com/F6N/5ES2/KG54C7DE/F6N5ES2KG54C7DE.jpg&filename=WIN_20201012_09_28_19_Pro.jpg)
This is really an amazing and easy project for everyone. built under $2.
you can also makesome of ypour own modifications.
really easy!
Supplies
super glue
bolts x2 (any size)
nuts x4(two for each bolts)
a piece of cardboard or plastic sheet(for base of the PCB holder)
Fix Bolts With a Base
![WIN_20201012_09_30_29_Pro.jpg](/proxy/?url=https://content.instructables.com/F0Z/ZFQX/KG54C80X/F0ZZFQXKG54C80X.jpg&filename=WIN_20201012_09_30_29_Pro.jpg)
![WIN_20201012_09_29_50_Pro.jpg](/proxy/?url=https://content.instructables.com/F1P/2V26/KG54C80Y/F1P2V26KG54C80Y.jpg&filename=WIN_20201012_09_29_50_Pro.jpg)
![WIN_20201012_09_31_51_Pro.jpg](/proxy/?url=https://content.instructables.com/FLX/KVVV/KG54C84L/FLXKVVVKG54C84L.jpg&filename=WIN_20201012_09_31_51_Pro.jpg)
you can see that i fixed the bolts with the base using super glue and kept the distance between them about
2 inches.
Adding Nuts
![WIN_20201012_09_35_54_Pro.jpg](/proxy/?url=https://content.instructables.com/FJR/Q4RD/KG54C810/FJRQ4RDKG54C810.jpg&filename=WIN_20201012_09_35_54_Pro.jpg)
To complete the holder, add nuts to it. kep them at same height to avoid any error whire soldering.
Testing
![WIN_20201012_09_42_29_Pro.jpg](/proxy/?url=https://content.instructables.com/F9E/BUO5/KG54C8FD/F9EBUO5KG54C8FD.jpg&filename=WIN_20201012_09_42_29_Pro.jpg)
Itested the stand and found it easy to use.
thank you.
