Blinking Hulk
Makers: Chakravrthi And kushal
Location: Banjarapalya E4D Maker space.
We made this project at Banjarapalya E4D Makerspace, for The Instructables Build Night On Circuit Scribe. We enjoy this build night and this Blinking hulk is looking so good.
Materials:
1.Conductive pen
2.A4 sheet
3.Photo sensor
4.NP N Transistor
5.LEDs
6.Buzzer
7.Blinkers
8. 9v Battery
Tools:
1.pencil
2.Eraser
3.Blade
4. Stencil
Draw the Hulk Face
First take one A4 sheet then draw the Hulk face with the help of pencil.
Plan the Circuit
Take another A4 sheet then plan the circuit for Hulk face, After planing draw the circuit with the help of conductive pen.
Fix the All Comonents
After draw the circuit take LED's, Blinker, Photo sensor, NP N transistor, 9V battery, Buzzer to and fix it to the circuit with the help of Steel pad as showing in the photo.
Put the Circuit Under the Drawing
After fixing all components take the circuit and put it under the Hulk drawing.
Final Step
After completing all steps it will look like this.
See Video
See video.
