Astley-izer

	/*
 * //////////////////////////////////////////////////
 * //making sense of the Parallax PIR sensor's output
 * //////////////////////////////////////////////////
 *
 * Switches a LED according to the state of the sensors output pin.
 * Determines the beginning and end of continuous motion sequences.
 *
 * @author: Kristian Gohlke / krigo(_)web.de / http://filformat.net
 * @date:   3. September 2006
 *
 * kr1 (cleft) 2006
 * released under a creative commons "Attribution-NonCommercial-ShareAlike 2.0" license
 * http://creativecommons.org/licenses/by-nc-sa/2.0/de/
 *
 *
 * The Parallax PIR Sensor is an easy to use digital infrared motion sensor module.
 * (http://www.parallax.com/detail.asp?product_id=555-28027)
 *
 * The sensor´s output pin goes to HIGH if motion is present.
 * However, even if motion is present it goes to LOW from time to time,
 * which might give the impression no motion is present.
 * This program deals with this issue by ignoring LOW-phases shorter than a given time,
 * assuming continuous motion is present during these phases.
 *


 */

/////////////////////////////
//VARS
#include
#include
#include "util.h"
#include "wave.h"

AF_Wave card;
File f;
Wavefile wave;

int calibrationTime = 30;	  //the time we give the sensor to calibrate itself (10-60 secs according to the datasheet)
long unsigned int lowIn;	   //the time when the sensor outputs a low impulse
long unsigned int pause = 5000;  //the amount of milliseconds the sensor has to be low before we assume all motion has stopped

boolean lockLow = true;
boolean takeLowTime;

int pirPin = 6;    //the digital pin connected to the PIR sensor's output
int ledPin = 13;


/////////////////////////////
//SETUP
void setup(){
  Serial.begin(9600);
  pinMode(pirPin, INPUT);
  pinMode(ledPin, OUTPUT);
  pinMode(2, OUTPUT);
  pinMode(3, OUTPUT);
  pinMode(4, OUTPUT);
  pinMode(5, OUTPUT);
  digitalWrite(pirPin, LOW);

  //give the sensor some time to calibrate
  Serial.print("calibrating sensor ");
    for(int i = 0; i < calibrationTime; i++){
	Serial.print(".");
	delay(1000);
	}
    Serial.println(" done");
    Serial.println("SENSOR ACTIVE");
    delay(50);
     if (!card.init_card()) {
   return;
 }
 if (!card.open_partition()) {
    return;
 }
 if (!card.open_filesys()) {
    return;
 }
 if (!card.open_rootdir()) {
    return;
 }
  }

////////////////////////////
//LOOP
void loop(){

     if(digitalRead(pirPin) == HIGH){
	 digitalWrite(ledPin, HIGH);   //the led visualizes the sensors output pin state
	 if(lockLow){
	   lockLow = false;		//make sure we wait for a transition to LOW before any further output is made
	   Serial.println("---");
	   Serial.print("motion detected at ");
	   Serial.print(millis()/1000);
	   Serial.println(" sec");
	   delay(50);
	   }
	   takeLowTime = true;
	 }

     if(digitalRead(pirPin) == LOW){
	 digitalWrite(ledPin, LOW);  //the led visualizes the sensors output pin state

	 if(takeLowTime){
	  lowIn = millis();	    //save the time of the transition from high to LOW
	  takeLowTime = false;	 //make sure this is only done at the start of a LOW phase
	  }

	 if(!lockLow && millis() - lowIn > pause){  //if the sensor is low for more than the given pause, we assume that no more motion is going to happen
	     lockLow = true;				//makes sure this block of code is only executed again after a new motion sequence has been detected
	     Serial.print("motion ended at ");	//output
	     Serial.print((millis() - pause)/1000);
	     Serial.println(" sec");
	     delay(50);
	     }
	 switch(digitalRead(pirPin) == HIGH){

   case 1:
     playcomplete("01NEVE~1.WAV");

 }
     }}



 void playcomplete(char *name) {
 playfile(name);
 while (wave.isplaying);
 card.close_file(f);
}

void playfile(char *name) {
 // stop any file already playing
 if (wave.isplaying) {
   wave.stop();
   card.close_file(f);
 }

 f = card.open_file(name);
 if (f && wave.create(f)) {
   wave.play();
 }


  }
