Arduino - Security Panel System With Using Keypad and LCD Display

In this tutorial we will learn how to make an Arduino Security Panel System with using Keypad and LCD Display.

We will be able to open the door by entering the correct password.

- Arduino Board - https://goo.gl/UyGYeF

- Keypad 4x4 - https://goo.gl/jtGlx5

- LCD 16x02 - https://goo.gl/8S27hc

- LED

- Wires - https://goo.gl/8S27hc / https://goo.gl/8S27hc

- Breadboard - https://goo.gl/8S27hc

- Resistor 220ohm

- Potentiometer 10k - https://goo.gl/8S27hc

- Recomended Site - https://goo.gl/3j489l

The Arduino's +5V and GND will be connected to the pin of the breadboard

The LCD has 16 pins and the first one from left to right is the Ground (GND) pin

The second pin is the VCC which we connect the +5V pin on the breadboard.

Next is the Vo pin on which we can attach a potentiometer for the contrast of the display

The RS pin will be connected to the A0 pin of the Arduino.

The RW pin will be connected to the GND pin of the breadboard.

The E pin will be connected to the A1 pin of the Arduino.

The D4 pin will be connected to the A2 pin of the Arduino.

The D5 pin will be connected to the A3 pin of the Arduino.

The D6 pin will be connected to the A4 pin of the Arduino.

The D7 pin will be connected to the A5 pin of the Arduino.

The A (anode) pin will be connected to the +5V pin of the breadboard.

The K (cathode) pin will be connected to the GND pin of the breadboard.

The potentiometer's other pins will be connected to the +5V and GND pin of the breadboard.

The keypad has 8 pins, 4 of them are for the rows and other 4 pin for the columns.

The keypad I'm using is 4x4. It has an additional connection input.

The keypad used in the circuit diagram is 3x4.

The Keypad's pins will be connected respectively to the Digital 1-2-3-4-5-6-7-8 pin of the Arduino.

The Red and Green LED will be attached on the breadboard

The 220 ohm resistor will be connected to the anode leg of the LED

The LED cathode leg will be connected to the GND of the breadboard.

The LED resistor leg will be connected to the Digital 10-11 of the Arduino.

Get the source code - https://goo.gl/hfgIv3

We need to include the standard LiquidCrystal library for the LCD Display

The Keypad library needs to be additionally installed.

Get the Keypad Library - https://goo.gl/PUiBBA

Put the Keypad folder in "arduino\libraries\"

Then we need to define the LED pins

Define some variables needed for the program

Define the keys of the Keypad
