Arduino - Multiple Servo Control With a Potentiometer

In this tutorial, we will learn how to use multi-servo with potentiometer. We will control 4 pcs servo motor with 4 pcs potentiometer.

You can implement your robotic arm projects with reference to this tutorial. Of course we will use external battery / power when doing this. In the next tutorial, I'll show you how to control servo motor with joystick.

Do not forget to subscribe. Thank you for your support.

Visit My Youtube Channel - Mert Arduino Tutorial & Projects

- Arduino Board

- Servo Motor x4

-10k Potentiometer x4

- Battery

- Wires and Breadboard

- The external battery VCC / GND connect to the breadboard.

- The Arduino GND connect to the breadboard's GND input

- The servo connections we use in this project are as follows;

Orange Input - Signal Input

Red Input - Power Input (VCC)

Brown Input - Ground Input(GND)

- The potentiometer connections we use in this project are as follows;

Two outer pins are power (VCC) and ground (GND)

Middle pin is signal pin

- The Servo1 VCC and GND connect to the breadboard's VCC / GND inputs

- The Servo1 Signal connect to the Arduino Digital PWM 3

- The Servo2 VCC and GND connect to the breadboard's VCC / GND inputs

- The Servo2 Signal connect to the Arduino Digital PWM 5

- The Servo3 VCC and GND connect to the breadboard's VCC / GND inputs

- The Servo3 Signal connect to the Arduino Digital PWM 6

- The Servo4 VCC and GND connect to the breadboard's VCC / GND inputs

- The Servo4 Signal connect to the Arduino Digital PWM 9

- The Potentiometer's one outer pin connect to the breadboard VCC input

- The Potentiometer's other outer pin connect to the breadboard GND input

- The Potentiometer's middle pin connect to the Arduino Analog 1-2-3-4 input

I did not share the code because it is short and it varies according to the number of servo,potentiometer.

You can write code by watching the tutorial. This is a better way to learn.

I will continue to share long and complex codes.
