Arduino Dino Game Using OLED Display

/** * Author: rayankiwan * Created: 9.8.2021 * instructable: * Email: rayankiwan63@gmail.com * * (c) Copyright by rayan kiwan. **/ // Include #include #include #include // Defines #define SCREEN_WIDTH 128 // OLED display width, in pixels #define SCREEN_HEIGHT 64 // OLED display height, in pixels #define OLED_RESET 4 // Reset pin # (or -1 if sharing Arduino reset pin) #define SCREEN_ADDRESS 0x3C #define DINO_WIDTH 25 #define DINO_HEIGHT 26 #define DINO_INIT_X 10 // Dino initial spawn location #define DINO_INIT_Y 29 // Dino initial spawn location #define BASE_LINE_X 0 #define BASE_LINE_Y 54 #define BASE_LINE_X1 127 #define BASE_LINE_Y1 54 #define TREE1_WIDTH 11 #define TREE1_HEIGHT 23 #define TREE2_WIDTH 22 #define TREE2_HEIGHT 23 #define TREE_Y 35 #define JUMP_PIXEL 22 // Number of pixel dino will jump Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, OLED_RESET); static const unsigned char PROGMEM dino1[]={ // 'dino', 25x26px 0x00, 0x00, 0x00, 0x00, 0x00, 0x07, 0xfe, 0x00, 0x00, 0x06, 0xff, 0x00, 0x00, 0x0e, 0xff, 0x00, 0x00, 0x0f, 0xff, 0x00, 0x00, 0x0f, 0xff, 0x00, 0x00, 0x0f, 0xff, 0x00, 0x00, 0x0f, 0xc0, 0x00, 0x00, 0x0f, 0xfc, 0x00, 0x40, 0x0f, 0xc0, 0x00, 0x40, 0x1f, 0x80, 0x00, 0x40, 0x7f, 0x80, 0x00, 0x60, 0xff, 0xe0, 0x00, 0x71, 0xff, 0xa0, 0x00, 0x7f, 0xff, 0x80, 0x00, 0x7f, 0xff, 0x80, 0x00, 0x7f, 0xff, 0x80, 0x00, 0x3f, 0xff, 0x00, 0x00, 0x1f, 0xff, 0x00, 0x00, 0x0f, 0xfe, 0x00, 0x00, 0x03, 0xfc, 0x00, 0x00, 0x01, 0xdc, 0x00, 0x00, 0x01, 0x8c, 0x00, 0x00, 0x01, 0x8c, 0x00, 0x00, 0x01, 0x0c, 0x00, 0x00, 0x01, 0x8e, 0x00, 0x00 }; static const unsigned char PROGMEM tree1[]={ // 'tree1', 11x23px 0x1e, 0x00, 0x1f, 0x00, 0x1f, 0x40, 0x1f, 0xe0, 0x1f, 0xe0, 0xdf, 0xe0, 0xff, 0xe0, 0xff, 0xe0, 0xff, 0xe0, 0xff, 0xe0, 0xff, 0xe0, 0xff, 0xe0, 0xff, 0xc0, 0xff, 0x00, 0xff, 0x00, 0x7f, 0x00, 0x1f, 0x00, 0x1f, 0x00, 0x1f, 0x00, 0x1f, 0x00, 0x1f, 0x00, 0x1f, 0x00, 0x1f, 0x00 }; static const unsigned char PROGMEM tree2[]={ // 'tree2', 22x23px 0x1e, 0x01, 0xe0, 0x1f, 0x03, 0xe0, 0x1f, 0x4f, 0xe8, 0x1f, 0xff, 0xfc, 0x1f, 0xff, 0xfc, 0xdf, 0xff, 0xfc, 0xff, 0xff, 0xfc, 0xff, 0xff, 0xfc, 0xff, 0xff, 0xfc, 0xff, 0xff, 0xfc, 0xff, 0xff, 0xfc, 0xff, 0xef, 0xfc, 0xff, 0x83, 0xfc, 0xff, 0x03, 0xfc, 0xff, 0x03, 0xf8, 0x7f, 0x03, 0xe0, 0x1f, 0x03, 0xe0, 0x1f, 0x03, 0xe0, 0x1f, 0x03, 0xe0, 0x1f, 0x03, 0xe0, 0x1f, 0x03, 0xe0, 0x1f, 0x03, 0xe0, 0x1f, 0x03, 0xe0 }; void setup() { // put your setup code here, to run once: Serial.begin(9600); // SSD1306_SWITCHCAPVCC = generate display voltage from 3.3V internally if(!display.begin(SSD1306_SWITCHCAPVCC, SCREEN_ADDRESS)) { Serial.println(F("SSD1306 allocation failed")); for(;;); // Don't proceed, loop forever } // Clear the buffer display.clearDisplay(); introMessage(); // Run game in loop while(1){ if (Serial.available()){ if(Serial.parseInt()==1){ play(); } } } } void loop() { // put your main code here, to run repeatedly: } void introMessage(){ display.setTextSize(2); // Draw 2X-scale text display.setTextColor(SSD1306_WHITE); display.setCursor(10,5); display.println("Dino Game"); display.setTextSize(1); display.setCursor(5,45); display.println("Enter 1 To Play "); display.display(); } // Move dino function void moveDino(int16_t *y, int type=0){ display.drawBitmap(DINO_INIT_X, *y, dino1, DINO_WIDTH, DINO_HEIGHT, SSD1306_WHITE); } // Move tree funciton void moveTree(int16_t *x, int type=0){ if(type==0){ display.drawBitmap(*x, TREE_Y, tree1, TREE1_WIDTH, TREE1_HEIGHT, SSD1306_WHITE); } else if(type==1){ display.drawBitmap(*x, TREE_Y, tree2, TREE2_WIDTH, TREE2_HEIGHT, SSD1306_WHITE); } } // Game over display with score void gameOver(int score=0){ display.clearDisplay(); display.setTextSize(2); // Draw 2X-scale text display.setTextColor(SSD1306_WHITE); display.setCursor(10,5); display.println("Game Over"); display.setTextSize(1); display.setCursor(10,30); display.print("Score: "); display.print(score); display.setCursor(1,45); display.println("Enter 1 To Play Again"); display.display(); } // Display score while running the game void displayScore(int score){ display.setTextSize(1); display.setCursor(64,10); display.print("Score: "); display.print(score); } // Main play function void play(){ int16_t tree_x=127; int16_t tree1_x=195; int tree_type = random(0,2); int tree_type1 = random(0,2); int16_t dino_y = DINO_INIT_Y; int input_command; int jump=0; int score=0; for(;;){ display.clearDisplay(); if (Serial.available()){ input_command = Serial.parseInt(); if(input_command==5){ Serial.println("Jump"); if(jump==0) jump=1; } } if(jump==1){ dino_y--; if(dino_y== (DINO_INIT_Y-JUMP_PIXEL)){ jump=2; score++; } } else if(jump==2){ dino_y++; if(dino_y== DINO_INIT_Y){ jump=0; } } if(tree_x<= (DINO_INIT_X+DINO_WIDTH) && tree_x>= (DINO_INIT_X+(DINO_WIDTH/2))){ // Serial.println("Might be Collision Happend"); if(dino_y>=(DINO_INIT_Y-3)){ // Collision Happened Serial.println("Collision Happend"); break; } } if(tree1_x<= (DINO_INIT_X+DINO_WIDTH) && tree1_x>= (DINO_INIT_X+(DINO_WIDTH/2))){ // Serial.println("Might be Collision Happend"); if(dino_y>=(DINO_INIT_Y-3)){ // Collision Happened Serial.println("Collision Happend"); break; } } displayScore(score); moveTree(&tree_x,tree_type); moveTree(&tree1_x,tree_type1); moveDino(&dino_y); display.drawLine(0, 54, 127, 54, SSD1306_WHITE); tree_x--; tree1_x--; if(tree_x==0) { tree_x = 127; tree_type = random(0,1); } if(tree1_x==0) { tree1_x = 195; tree_type1 = random(0,1); } display.display(); } Serial.println("Game Over"); gameOver(score); } void renderScene(int16_t i=0){ display.drawBitmap(10, 29, dino1, 25, 26, SSD1306_WHITE); display.drawBitmap(50, TREE_Y, tree1, 11, 23, SSD1306_WHITE); display.drawBitmap(100, TREE_Y, tree2, 22, 23, SSD1306_WHITE); display.drawLine(0, 54, 127, 54, SSD1306_WHITE); display.drawPixel(i, 60, SSD1306_WHITE); }
